Matrix h5x-02 User Manual

28
8.4 CUP HOLDER REPLACEMENT
CHAPTER 8: PART REPLACEMENT GUIDE
1) Remove the 2 screws holding the cup holder to the console mast (Figure A).
2) Remove the cup holder (Figure B).
3) Reverse Steps 1-2 to install a new cup holder.
FIGURE A
FIGURE B
