Matrix h5x-02 User Manual

47
8.20 FRONT STABILIZER REPLACEMENT
1) Lean the bike to one side and remove the 4 screws holding the front stabilizer to the frame (Figure A).
2) Remove the front stabilizer (Figure B).
3) Reverse Steps 1-2 to install a new front stabilizer.
FIGURE A
FIGURE B
CHAPTER 8: PART REPLACEMENT GUIDE

Matrix h5x-02 Specifications

General

Brand	Matrix
Model	h5x-02
Category	Exercise Bike
Language	English
