Matrix h5x-02 User Manual

33
FIGURE B
FIGURE A
1) Remove the 4 screws holding the seat pad to the seat post (Figure A).
2) Lift the seat pad away from the seat post (Figure B).
3) Reverse Steps 1-2 to install a new seat pad.
8.7 SEAT PAD REPLACEMENT
CHAPTER 8: PART REPLACEMENT GUIDE
