8.3 DAUGHTER BOARD LED INSTRUCTIONS
LED REFERENCE
DESIGNATOR
DESCRIPTION
DIAGNOSTIC 1 LED 1 Indicates the PCB with Daughter Board communication
present.
DIAGNOSTIC 2 LED 2 Indicates the MCB with Daughter Board communication
present.
POWER / ALIVE LED 3 Indicates if MCB Voltage Supply is present.
CHAPTER 8: TROUBLESHOOTING
