Miele T 4859 Ci User Manual

Changing the lamp
Disconnect the tumble dryer from
the mains electricity supply.
^
Open the door.
You will find the interior light cover at
the top of the drum aperture.
^ Insert a suitable tool, such as a wide
bladed screwdriver, under the side
edge of the light cover as illustrated.
^
Apply a little pressure and whilst
doing so turn your wrist in the
direction of the arrow to open the
cover.
The cover will open downwards.
The temperature resistant lamp should
only be ordered from your Miele Dealer
or the Miele Spare Parts Department.
The light specification and maximum
wattage is stated on the data plate
and on the light cover.
^
Turn the light anti-clockwise to
remove.
^
Replace the lamp.
^
To close the cover push it upwards
and press it on the left and right until
you hear it click into position.
,
Ensure that it is fitted into
position securely, as any moisture
could cause a short circuit.
Problem solving guide
51

Miele T 4859 Ci Specifications

General

Control type	Buttons
Display type	LCD
Loading type	Front-load
Drying system	Condensation
Product color	Stainless steel
Built-in display	Yes
Appliance placement	Freestanding
Drying class	-
Drum capacity	6 kg
Maximum spin speed	1400 RPM
Delay start (max)	24 h
Current	13 A
Connected load	2850 W
AC input voltage	220-230 V
AC input frequency	50 Hz
Energy consumption	3.35 kWh
Annual energy consumption	265 kWh

Weight and Dimensions

Depth	575 mm
Width	595 mm
Height	820 mm
Weight	52000 g
Depth with door open	1150 mm
