Miele T 4859 Ci User Manual

External condensed water
outlet
General notes
When drying is in progress, condensed
water is pumped into the condensed
water container through the drain hose
at the back of the dryer. The
condensed water can also be drained
off directly if the dryer is installed near a
sink, drain outlet etc. so that the
condensed water container does not
have to be emptied.
Drain hose length ............1.00 m
Extension hose ..............2.00 m
(accessory)
Maximum delivery head .......1.50 m
Maximum drain hose length ....4.00 m
,
If the on-site water drainage
system is not fitted with a non-return
valve or an appropriate air gap, an
air gap or the non-return valve
supplied with the dryer must be
fitted to prevent the risk of
back-flow. (See "Installation
conditions requiring a non-return
valve").
Maximum delivery head
with non-return valve fitted .....1.00 m
Arranging the drain hose
,
Do not pull on the drain hose
and do not stretch it or allow it to
become kinked as it could get
damaged.
^
Unclip the drain hose from clips (1)
and (2).
^ Then pull it off connection (3).
^
The lower clip (4) can be opened to
allow you to take the drain hose out
or to feed the mains cable through it.
Installation and connection
61

Miele T 4859 Ci Specifications

General

Control type	Buttons
Display type	LCD
Loading type	Front-load
Drying system	Condensation
Product color	Stainless steel
Built-in display	Yes
Appliance placement	Freestanding
Drying class	-
Drum capacity	6 kg
Maximum spin speed	1400 RPM
Delay start (max)	24 h
Current	13 A
Connected load	2850 W
AC input voltage	220-230 V
AC input frequency	50 Hz
Energy consumption	3.35 kWh
Annual energy consumption	265 kWh

Weight and Dimensions

Depth	575 mm
Width	595 mm
Height	820 mm
Weight	52000 g
Depth with door open	1150 mm
