Installation site
,
Make sure the dryer door can be
opened without hindrance after
installation.
Building under a continous worktop /
in a kitchen run
This tumble dryer is specially designed
for installation under a continuous
worktop run in a fitted kitchen.
N = Niche height (820-930 mm)
When moving the dryer do not lift it
by the drum door.
The dryer is supplied fitted with a
cover plate instead of a machine lid.
The cover plate is necessary to
ensure electrical safety and must not
be removed.
–
Slides* can be used to protect the
floor from damage when the machine
is pushed into position or taken out
for servicing.
– The electrical socket must be
located in an accessible position
near the tumble dryer.
Please note:
Niche height Additional accessories
required
820 mm None
from
830-840 mm
Fit longer screw feet* (set to
approx. 40 mm)
from
870-885 mm
One raising kit*
from
915-930 mm
Two raising kits*
* these accessories are available to order
The tumble dryer must not be used
without the front panel in place.
If the kitchen run has a continuous
furniture plinth in place, a gap must
be made for the tumble dryer.
Installation and connection
54

Miele T 4859 Ci Specifications

General

Control type	Buttons
Display type	LCD
Loading type	Front-load
Drying system	Condensation
Product color	Stainless steel
Built-in display	Yes
Appliance placement	Freestanding
Drying class	-
Drum capacity	6 kg
Maximum spin speed	1400 RPM
Delay start (max)	24 h
Current	13 A
Connected load	2850 W
AC input voltage	220-230 V
AC input frequency	50 Hz
Energy consumption	3.35 kWh
Annual energy consumption	265 kWh

Weight and Dimensions

Depth	575 mm
Width	595 mm
Height	820 mm
Weight	52000 g
Depth with door open	1150 mm
