Miele T 4859 Ci User Manual

Fitting a plinth facing
The gap between the lower edge of the
tumble dryer plinth and the floor can be
closed up using a suitable kitchen
furniture plinth facing.
The tumble dryer plinth has a special
groove in which a plinth facing can be
fitted.
Plinth facing dimensions
Length
: 592 - 596 mm
Thickness
:8mm
Height (
H): The plinth facing height
must be calculated after aligning the
height of the appliance with the screw
feet or after fitting the raising kit(s).
Installation
^
Calculate height (H) from the floor up
into the groove (on the underside of
the tumble dryer).
^
Cut the plinth facing to size.
^
Slide it into the groove.
Useful tip:
If the dryer is fitted on a raising kit, you
can use double-sided adhesive tape on
the back of the plinth facing to secure it
to the raising kit.
Installation and connection
60

Miele T 4859 Ci Specifications

General

Control type	Buttons
Display type	LCD
Loading type	Front-load
Drying system	Condensation
Product color	Stainless steel
Built-in display	Yes
Appliance placement	Freestanding
Drying class	-
Drum capacity	6 kg
Maximum spin speed	1400 RPM
Delay start (max)	24 h
Current	13 A
Connected load	2850 W
AC input voltage	220-230 V
AC input frequency	50 Hz
Energy consumption	3.35 kWh
Annual energy consumption	265 kWh

Weight and Dimensions

Depth	575 mm
Width	595 mm
Height	820 mm
Weight	52000 g
Depth with door open	1150 mm
