Installation and connection
83
Changing the door hinging
You can change the door hinging on
this
tumble dryer yourself.
For safety reasons the tumble
dryer must be disconnected from the
electricity supply before changing
the door hinging.
You will need:
– a Torx T20 and T30 screwdriver
– a flat head screwdriver or pointed pli‐
ers
– the lock catch cover supplied
– the door hinge cover supplied
– a soft surface (e.g. a tablecloth)
Changing the hinging over
1. Remove the door from the dryer
Open th
e door.
Us
e a T30 Torx screwdriver to un‐
screw the two screws on the base
plate of the door hinge .
The door cannot fall off as it is held in
place by 2 pins.
Ho
ld the door securely and pull it for‐
wards: to remove the door you will
need to pull the base plate of the
hinge with its 2 pins out of the dryer.
To avoid scratching the door, place it
ou
ter side downwards on a soft sur‐
face (e.g. a tablecloth).
2. Change over the door lock on the
dr
yer
Use
a Torx T30 screwdriver to un‐
screw the two screws on the door
lock .
Use the screwdriver to press the door
lock upwards.
The door lock will spring out of its posi‐
tion an
d can then be removed.
