Milnor C Series User Manual

4
Pellerin Milnor Corporation
2 Controls
BNWUUO03 / 2020403
BNWUUO03 0000267770 A.5 9/29/20 9:34 AM Released
2.1 Physical Controls
BNWUUO03.R01 0000267801 A.10 A.5 9/16/20 9:06 AM Released
The following figure shows how the control panel appears on 30022V8Z, 30015V8Z,
30022VZZ, and 30015VZZ machines.
Figure 1. Control Panel
Legend
A...Master power
switch
B...Door unlock button
C...USB port
The following figure shows how the control panel appears on 36021V5Z, 36021V7Z, 36026V5Z,
36026V7Z, 42026V6Z, and 42030V6Z machines.
Figure 2. Control Panel
Legend
A...Door unlock button
B...Master power switch
