Mindray BeneView T6 Service Manual

5-20
5.4.12 Removing the Fan
Disconnect the connector that connects the fan and the mother board. Then unscrew the three
M3×6 screws and remove the fan.
5.4.13 Removing the Speaker
Disconnect the connector that connects the speaker and the mother board. Then unscrew the
two M3×6 screws and remove the speaker.
CAUTION
z When installing a speaker, be sure to keep the cable from the press bar. Otherwise,
the speaker may be short-circuited.
