Setup 12-5
Type
Item
Description
Steer
To set the steer mode in B+ Color +PW imaging mode.
C&PW: select to adjust the sample volume in color
mode and sample line in PW mode together.
C/PW: select to adjust the sample volume in color
mode and sample line in PW mode individually.
Auto Invert
The spectrum can automatically invert when the color
flow is steered to a certain angle, thus accommodating
operator’s habit of distinguishing flow direction.
Cine Memory To set the cine memory splitting type.
iScape Ruler
Display
To set if to display the iScape ruler on iScape imaging
mode.
12.1.4 Application
Open the Meas page via [Setup]-> [System Preset]-> [Application]. Through the page, you
can set the measure ruler, follicle and relevant information. For details, please refer to the
Operator’s Manual [Advanced Volume]
12.1.5 OB
Open the OB page via [Setup]-> [System Preset]-> [OB]. Through the page, you can set the
gestational age formula, fetal growth formula, fetal weight formula and the relevant
information. For details, please refer to the Operator’s Manual [Advanced Volume].
12.1.6 Key Config
Open the page via [Setup]-> [System Preset]-> [Key Config], as shown in the figure below.
