3-10 System Preparation
3.11 Basic Screen and Operation
3.11.1 Basic Screen
The following diagram maps out the different areas in the screen:
Logo
Hospital name
Patient Information
Accession#
Freeze
icon
Operator Exam time
Probe
Acoustic power, MI/TI
Menu area Image area
Product Mode
Exam Mode
Image Parameters
Thumbnail
preview&
zoom
window
Cine Review Area
Bodymark & Comment
Thumbnail Area of Images Saved
Help information area
System status icon
 Information Area
The information area displays manufacturer logo, hospital name, exam date & time,
acoustic power & MI/TI, freeze icon, patient information, probe model, current exam mode,
and accession #, etc. It can be preset whether to display the operator, patient gender, age,
ID, name etc. via [Setup]-> [System Preset]-> [General]. See “12.1.2 General” for detailed
preset procedures.
 Menu area
Include image menu, measurement menu, comment menu, bodymark menu and so on.
Use the trackball or the multifunctional knob to operate on the menu.
 Image area
The image area displays the ultrasound images, probe mark (or activating window mark),
time line (in M mode), coordinate axis (including depth, time, velocity/frequency), focus
position (located at depth axis in the form of
), besides, the annotation, bodymark,
measurement calipers, grayscale bar are also displayed here.
 Grayscale/ color bar
Displays the grayscale/ color bar corresponding to the current mode.
