Technical Speciﬁcations

Technical Specications

WARNING

Any changes or modiﬁcations not expressively approved by Minelab Electronics Pty Ltd could void the user’s

authority to operate this equipment.

GPZ7000 Technical Specications

Transmission Full Band Spectrum 2 (FBS 2)

Simultaneous Frequency Transmission ranging from 1.5–100 kHz

Coil 14” DOD - Standard (accessory coils available)

Audio Output Headphones, WiStream Wireless Audio

Liquid Crystal Display (LCD) Full colour, 320 x 240 pixels, 2.83” x 2.12” (72 mm x 54 mm)

GPS Engine u-blox Neo-6

FindPoints Up to 100 (FP001 - FP100)

WayPoints Up to 100 (WP001 - WP100)

GeoHunts Up to 10 (GH001 - GH010)

Length Collapsed: 36.77” (934 mm) Laid ﬂat, packed position: 40.66” (1033 mm)

Extended: 55.15” (1401 mm) Laid ﬂat, packed position: 59.05” (1500 mm)

Detector Weight 5.2 lb (2.36 kg) (with Li-Ion battery installed)

Coil Weight (including Skid

plate)

1.4 lb (641 g)

Operating Temperature Range 32°F to 113°F (0°C to 45°C)

Operating Humidity Range Up to 95% non-condensing

Storage Temperature Range 23°F to 150°F (–5°C to 70°C)

Storage Humidity Range Up to 98% Relative Humidity

Operating Time (Li-Ion Battery) 8 hours (GPS, backlight, speaker enabled)

Battery Technical Specications

Type Li-Ion Rechargeable Battery Pack

Output Voltage Li-Ion: 7.2 V Nominal

Capacity Li-Ion: 34 Wh

Charge Time Up to 4 hours

Weight Li-Ion pack: 0.56 lb (255 g)

Battery Operating Temperature 32°F to 113°F (0°C to 45°C)

Battery Storage Temperature 23°F to 176°F (–5°C to 70°C)

BC 10 Battery Charger Technical Specications

BC 10 Operating Temperature 14°F to 113° F (-10°C to 45°C)

BC 10 Storage Temperature -22°F to 176°F (-30°C to 80°C)

BC 10 Input Voltage 11 to 30 VDC

BC 10 USB Output Current 500 mA
