10.5 Program Example when ACPU/QCPU (A Mode) is Used (Dedicated Command)
The network parameter and the automatic refresh parameter are set by the
sequence program.
10.5.1 Program example of coincidence output function
Network parameter settings with dedicated command RLPA
Automatic refresh parameter settings with dedicated command RRPA
Synchronous mode is
invalid.
No. of modules
connected: 1
Station information of
high-speed counter
module (remote device
station, 4 stations
occupied, station number 1)
Dedicated command
(RLPA)
Head I/O number of
master module
Parameter storage
head device
Device that turns on
1 scan at completion
Parameter status
reading at abnormal
completion
RX head number is
set.
"X" is set.
X400 is set.
128 points is set.
RY head number is
set.
"Y" is set.
Y400 is set.
128 points is set.
RW head number is
set.
"D" is set.
D200 is set.
263 points is set.
