8. EXECUTING THE RING COUNTER FUNCTION
8 - 1
8. EXECUTING THE RING COUNTER FUNCTION
This chapter describes the ring counter function.
8.1 Ring Counter Function
The ring counter function repeats counting between the preset value set by the ring
counter command and the ring counter value.
The ring counter function can be used for control such as fixed-pitch feed.
When using the ring counter, preset the ring counter setting switch of the high-speed
counter module to ON. Also, set the preset value and ring counter value to the remote
registers.
[Remote registers used]
Address Description
RWwm+0
CH1 Preset value setting area
(L)
RWwm+1 (H)
RWwm+3
CH1 Coincidence output point No. 1 setting area
(L)
RWwm+4 (H)
RWwm+8
CH2 Preset value setting area
(L)
RWwm+9 (H)
RWwm+B
CH2 Coincidence output point No. 2 setting area
(L)
RWwm+C (H)
