Mitsubishi City Multi PEFY-P72NMHSU-E User Manual

53- 53 -
HWE10170 GB
5. Address switch setting
Make sure that power to the unit is turned off.
Indoor controller board
1. Address is set with a combination of SW12 (10's digit) and SW11 (1's digit).
To set the address to "3," set SW12 to "0" and SW11 to "3."
To set the address to "25," set SW 12 to "2" and SW 11 to "5."
SW1
SW4
SW2 SW3
SWA
SW5
SWC
SW14 SW12 SW11
HWE10170.book 53 ページ ２０１１年７月１９日 火曜日 午後２時５７分
