[2] Specifications
1. Specifications
*1 <Cooling> Indoor temperature: 80°FD.B./67°FW.B. (26.7°CD.B./19.4°CW.B.) Outdoor temperature: 95°FD.B.(35°CD.B.)
<Heating> Indoor temperature: 70°FD.B.(21.1°CD.B.) Outdoor temperature: 47°FD.B./43°FW.B. (8.3°CD.B./6.1°CW.B.)
*2 Measured at a power supply voltage of 230 V
Model PEFY-P72NMHSU-E PEFY-P96NMHSU-E
Power supply
Voltage V 1-phase 208-230
Frequency Hz 50/60
Capacity*1 Cooling kW[BTU/h] 21.1 (72,000) 28.1 (96,000)
Heating kW[BTU/h] 23.4 (80,000) 31.7 (108,000)
Power consumption
50Pa
[0.20in.WG]
Cooling kW
0.43 0.59
Heating kW
100Pa
[0.40in.WG]
Cooling kW
0.52 0.70
Heating kW
150Pa
[0.60in.WG]
Cooling kW
0.63 0.82
Heating kW
200Pa
[0.80in.WG]
Cooling kW
0.75 0.95
Heating kW
250Pa
[1.00in.WG]
Cooling kW
0.89 0.97
Heating kW
Current consumption
*2
50Pa
[0.20in.WG]
Cooling A
2.31 3.08
Heating A
100Pa
[0.40in.WG]
Cooling A
2.79 3.75
Heating A
150Pa
[0.60in.WG]
Cooling A
3.32 4.43
Heating A
200Pa
[0.80in.WG]
Cooling A
3.95 5.10
Heating A
250Pa
[1.00in.WG]
Cooling A
4.81 5.29
Heating A
External finish Galvanized
Dimensions Height mm[in.] 470 (18-9/16)
Width mm[in.] 1250 (49-1/4)
Depth mm[in.] 1120 (44-1/8)
Net weight 97 100
Heat exchanger Cross fin (Alminium fin and copper tube)
Fan Type Sirocco fan x 2
Airflow rate (H-M-L)
m
3
/min
[cfm]
72-61-50
2542-2154-1766
84-71-58
2966-2507-2048
External static
pressure
Pa
[in.WG]
(50)/(100)/150/(200)/(250)
(0.20)/(0.40)/0.60/(0.80)/(1.00)
Motor Output kW 0.87
Air filter Option
Refriferant pipe dimensions Gas
(Brazed connection)
mm ø19.05 ø22.2
[in.] ø3/4 ø7/8
Liquid
(Brazed connection)
mm ø9.52
[in.] ø3/8
Drain pipe dimensions mm O.D.32
[in.] 1-1/4
Operating noise (H-M-L) 50Pa [0.20in.WG] dB(A) 39-35-32 42-38-35
100Pa [0.40in.WG] 41-37-34 44-40-37
150Pa [0.60in.WG] 43-39-36 46-42-39
200Pa [0.80in.WG] 45-41-38 48-44-41
250Pa [1.00in.WG] 47-43-40 50-46-43
*
Measured in anechoic room.
2m
1m
Aux. duct
1.5m
Measurement location 2
