1.3 System Configuration
Figure 1.3:System Configuration
*1 The units at each end of the Profibus-DP network must have a terminating resistor. This
will either be in the master or slave unit or in the Profibus connector.
*2 For connecting monitoring tool, refer to section 1.3.1
*3 For connecting extension I/O units/blocks and special function blocks, refer to section
1.3.2.
Caution
The parameter data of the 32DP-IF must be set correctly in the DP-master, If the parameter
data are not correct, the operation of the module might be affected. For a detailed overview of
the parameter of 32DP-IF, refer to chapter 6.
DP-master
Slave or
DP-master *
1
FX
2N
-32DP-IF Profibus-DP
interface unit *
2
Profibus-DP network
Extension I/O units/blocks and
special function blocks *
3
Slave or
DP-master *
1
