7.2 Buffer memory details

FX3U-64CCL User's Manual

7.2.14 [BFM#120 to 133] Remote output (RY)

These remote output (RY) buffer memory addresses store the ON/OFF information received from the master

station.

Read these buffer memory addresses using the FROM instruction (or direct buffer memory specification) to

use the stored ON/OFF information.

For the buffer memory allocation in accordance with the number of occupied stations and expanded cyclic

transmission, refer to the next page.

1) Details for the buffer memory allocation related to remote outputs (RY)

The table below shows details for the buffer memory allocation related to remote outputs (RY)

BFM No. bit15 bit14 bit13 bit12 bit11 bit10 bit9 bit8 bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0

#120 RY00F RY00E RY00D RY00C RY00B RY00A RY009 RY008 RY007 RY006 RY005 RY004 RY003 RY002 RY001 RY000

#121 RY01F RY01E RY01D RY01C RY01B RY01A RY019 RY018 RY017 RY016 RY015 RY014 RY013 RY012 RY011 RY010

#122 RY02F RY02E RY02D RY02C RY02B RY02A RY029 RY028 RY027 RY026 RY025 RY024 RY023 RY022 RY021 RY020

#123 RY03F RY03E RY03D RY03C RY03B RY03A RY039 RY038 RY037 RY036 RY035 RY034 RY033 RY032 RY031 RY030

#124 RY04F RY04E RY04D RY04C RY04B RY04A RY049 RY048 RY047 RY046 RY045 RY044 RY043 RY042 RY041 RY040

#125 RY05F RY05E RY05D RY05C RY05B RY05A RY059 RY058 RY057 RY056 RY055 RY054 RY053 RY052 RY051 RY050

#126 RY06F RY06E RY06D RY06C RY06B RY06A RY069 RY068 RY067 RY066 RY065 RY064 RY063 RY062 RY061 RY060

#127 RY07F RY07E RY07D RY07C RY07B RY07A RY079 RY078 RY077 RY076 RY075 RY074 RY073 RY072 RY071 RY070

#128 RY08F RY08E RY08D RY08C RY08B RY08A RY089 RY088 RY087 RY086 RY085 RY084 RY083 RY082 RY081 RY080

#129 RY09F RY09E RY09D RY09C RY09B RY09A RY099 RY098 RY097 RY096 RY095 RY094 RY093 RY092 RY091 RY090

#130 RY0AF RY0AE RY0AD RY0AC RY0AB RY0AA RY0A9 RY0A8 RY0A7 RY0A6 RY0A5 RY0A4 RY0A3 RY0A2 RY0A1 RY0A0

#131 RY0BF RY0BE RY0BD RY0BC RY0BB RY0BA RY0B9 RY0B8 RY0B7 RY0B6 RY0B5 RY0B4 RY0B3 RY0B2 RY0B1 RY0B0

#132 RY0CF RY0CE RY0CD RY0CC RY0CB RY0CA RY0C9 RY0C8 RY0C7 RY0C6 RY0C5 RY0C4 RY0C3 RY0C2 RY0C1 RY0C0

#133 RY0DF RY0DE RY0DD RY0DC RY0DB RY0DA RY0D9 RY0D8 RY0D7 RY0D6 RY0D5 RY0D4 RY0D3 RY0D2 RY0D1 RY0D0
