Appendix B: Differences with FX2N-32CCL
Appendix B-2 List of buffer memory compatible with FX2N-32CCL
65
FX3U-64CCL User's Manual
B
Differences with
FX
2N
-32CCL
Appendix B-2 List of buffer memory compatible with FX2N-32CCL
The table below describes BFM #0 to #31 , which are compatible with the FX2N-32CCL.
BFM No.
Read/
Write
Description
Read (FROM
instruction)
Write (TO
instruction)
Explanation (compatibility etc.)
#0 R/W Remote RX, RY RY00-0F RX00-0F
FX2N-32CCL compatible area
#1 R/W Remote RX, RY RY10-1F RX10-1F
#2 R/W Remote RX, RY RY20-2F RX20-2F
#3 R/W Remote RX, RY RY30-3F RX30-3F
#4 R/W Remote RX, RY RY40-4F RX40-4F
#5 R/W Remote RX, RY RY50-5F RX50-5F
#6 R/W Remote RX, RY RY60-6F RX60-6F
#7 R/W Remote RX, RY RY70-7F RX70-7F
#8 R/W Remote register RWw0 RWr0
#9 R/W Remote register RWw1 RWr1
#10 R/W Remote register RWw2 RWr2
#11 R/W Remote register RWw3 RWr3
#12 R/W Remote register RWw4 RWr4
#13 R/W Remote register RWw5 RWr5
#14 R/W Remote register RWw6 RWr6
#15 R/W Remote register RWw7 RWr7
#16 R/W Remote register RWw8 RWr8
#17 R/W Remote register RWw9 RWr9
#18 R/W Remote register RWwA RWrA
#19 R/W Remote register RWwB RWrB
#20 R/W Remote register RWwC RWrC
#21 R/W Remote register RWwD RWrD
#22 R/W Remote register RWwE RWrE
#23 R/W Remote register RWwF RWrF
#24 R
Transmission rate set
value
Rotary switch
setting value
Writing is
impossible.
The rotary switch setting information is stored.
Several settings are added to the settings available
for the FX2N-32CCL.
#25 R Communication status
Communication
status stage
The communication status is stored.
Several settings are added to the settings available
for the FX2N-32CCL.
#26 R CC-Link model code H0101 The CC-Link model code is stored.
#27 R
Set value of host station
number
Rotary switch
setting value
The rotary switch setting information is stored.
#28 R
Number of occupied
stations, expanded
cyclic set value
Rotary switch
setting value
The rotary switch setting information is stored.
Several settings are added to the settings available
for the FX2N-32CCL.
#29 R Error code Error code
Error information is stored.
Several settings are added to the settings available
for the FX
2N-32CCL.
#30 R FX Series model code K7160
The model code K7160 of 64CCL is stored.
(The model code of FX
2N-32CCL is K7040.)
#31 R Not available ---- ----
