14. COMMUNICATION FUNCTION
14 - 27
(5) Reading output device status
Read the on/off status of the output devices.
(a) Transmission
Transmit command [1] [2] and data No. [8] [0].
Command Data No.
[1] [2] [8] [0]
(b) Return
The slave station returns the status of the input/output devices.
b31 b1b0
1: On
0: Off
Command of each bit is transmitted to the master station as hexadecimal data.
Bit Symbol Bit Symbol Bit Symbol Bit Symbol
0 RD 8 ALM 16 24
1 SA 9 OP 17 25 CDPS
2 ZSP 10 MBR 18 26 CLDS
3 TLC 11 DB 19 27 ABSV
4 VLC 12 ACD0 20 28
5 INP 13 ACD1 21 29
6 14 ACD2 22 30
7 WNG 15 BWNG 23 31 MTTR
14.5.5 Input device on/off
POINT
The on/off status of all devices in the servo amplifier are the status of the data
received at last. Therefore, when there is a device which must be kept on,
transmit data which turns the device on every time.
Each input device can be switched on/off. However, when the device to be switched off is in the external
input signal, also switch off the input signal.
Transmit command [9] [2], data No. [6] [0], and data.
Command Data No. Set data
[9] [2] [6] [0] See below.
b31 b1b0
1: On
0: Off
Command of each bit is transmitted to the master station as hexadecimal data.
Bit Symbol Bit Symbol Bit Symbol Bit Symbol
0 SON 8 SP1 16 24
1 LSP 9 SP2 17 25
2 LSN 10 SP3 18 26
3 TL 11 ST1/RS2 19 27 CDP
4 TL1 12 ST2/RS1 20 STAB2 28 CLD
5 PC 13 CM1 21 29 MECR
6 RES 14 CM2 22 30
7 CR 15 LOP 23 31
