6.11 Monitor Function
6.11.3 Forced ON/OFF for external I/O
6
FUNCTIONS
(3) Operation procedure
Note6.18
Note20
The operation procedure is explained below.
• Register enforced ON/OFF for the specified device.
[Online] [Debug] [Forced input output registration/cancellation]
• It is possible to perform enforced ON or enforced OFF for a specified device
by selecting [Set forced ON] or [Set forced OFF] after the device has been
specified on the [Registration forced ON/OFF] setup screen.
Note20
Figure 6.39 Forced input output registration/cancellation screen
Table6.21 Enforced I/O registration/cancel screen items
No. Name of setup field Function description
1) Device
Enter the I/O number for which enforced ON/OFF is to be
set, or for which enforced ON/OFF is to be cancelled.
2)
Registration status
displayed area
Displays the registration status of registered enforced input
and output.
3) Update Displays the registration status loaded from CPU module.
4) Set forced ON/OFF
Performed enforced ON/OFF registration for specified
devices.
5) Cancel it Cancels the enforced ON/OFF for registered devices.
6) Clear all Cancels all registered enforced I/O registrations.
Basic
Note6.18
The enforced ON registration and enforced OFF registration cannot be executed for Basic model
QCPU by selecting [Online] [Debug] [Forced input output registration/cancellation]. This
operation can be executed for Basic model QCPU by conducting device test with GX Developer.
Basic
Note6.18
1)
5)
4)
6)
3)
2)
