Mitsubishi Q02CPU User Manual

11 - 17
11.1 Scan Time
11.1.2 Time required for each processing included in scan time
11
CPU MODULE PROCESSING TIME
(8) Low speed program operation time
Note11.7
Note7
The low speed program operation time is the sum of processing times of the
instructions used in the low speed execution type program to be executed by the CPU
module.
The processing times are the same as those in (4) of this section.
(9) Common processing time
This indicates the processing time common to the CPU modules.
Table11.17 shows the common processing time for each CPU module model.
(10)Multiple CPU high speed transmission processing time
The Multiple CPU high speed transmission processing time is the required time for
Multiple CPU data transmission when the Multiple CPU high speed transmission
function is used.
Refer to the following manual for the Multiple CPU high speed transmission
processing time.
QCPU User's Manual (Multiple CPU System)
Note7
Table11.17 Common processing time
CPU module Common processing time
Q00JCPU 0.66ms
Q00CPU 0.60ms
Q01CPU 0.52ms
Q02CPU 0.40ms
Q02HCPU, Q06HCPU, Q12HCPU, Q25HCPU,
Q02PHCPU, Q06PHCPU, Q12PHCPU,
Q25PHCPU
0.16ms
Q12PRHCPU, Q25PRHCPU 0.5ms
Q02UCPU 0.17ms
Q03UDCPU 0.12ms
Q04UDHCPU, Q06UDHCPU, Q13UDHCPU,
Q26UDHCPU
0.09ms
Q03UDECPU 0.21ms
Q04UDEHCPU, Q06UDEHCPU,
Q13UDEHCPU, Q26UDEHCPU
0.17ms
Basic
Redundant
Note11.7
Universal
UD
Since the Basic model QCPU, Redundant CPU and Universal model QCPU cannot use low
speed execution type programs, it is not necessary to be conscious of the low speed execution
type program operation time.
Basic
Note11.7
Redundant
Universal
UD
