3-8
Chapter 3 OPERATION
Specific Gravity of Batt
ery Electrolyte - Check
If the specific gravity measured at 20°C [68°F] is lower
than 1.22, charge the battery
.
Fig. 3-14 S
pecific Gravity of Battery Electrolyte -
Check
T
able 3-1 S
pecific Gravity of Electrolyte
S
pecific gravity
at 20°C [68°F]
Conditions
Remedy
From 1.26 to 1.28
Fully charged
-
From 1.22 to 1.26
Partially
charged
Charge
Less than 1.22
Discharged
Charge
Float
Electrolyte
surface
Electrolyte
Glass tube
39
41
