Specifications
The specifications and outside appearance of the projector are subject to change without prior notice.
Type DLP™ projector
Model UD8400U/UD8400LU/UD8350U/UD8350LU
Display technology 0.67-inch Single chip DMD
Pixel 1920 x 1200 = 2304000 pixels
Projection lens F 2.0 - 2.4*
1
f= 24.5 - 33.1 mm*
1
Light-source lamp 330 W x 2
Image size (projection distance) 40” min. to 300” max.*
1
(projection distance 1.4 to 10.9 m*
1
)
Maximum resolution Computer signal Maximum resolution: 1920 x 1200 dots
Panel resolution: 1920 x 1200 dots
Video signal NTSC/PAL/SECAM/4.43NTSC/PAL-M/PAL-N/PAL-60
Component signal 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Panel resolution: 1920 x 1200 dots
Computer/component video input [Signal type] [Terminal type] [Line]
Analog RGB Mini D-SUB 15-pin 1
Analog RGB 5 BNC 1
Digital RGB DVI-D 24-pin 1
Video input [Signal type] [Terminal type] [Line]
Video input BNC 1
S-video input S 1
HDMI input [Signal type] [Terminal type] [Line]
HDMI HDMI 19-pin 1
SDI input*
2
[Signal type] [Terminal type] [Line]
SDI BNC 1
Control terminal/others SERIAL IN/OUT (D-SUB 9-pin male) RS-232C standards,
LAN (RJ-45), REMOTE 1 IN (D-SUB 9-pin female), REMOTE2 IN/OUT
(Stereominijack(ø3.5))
Operating temperatures +41°F (+5°C) to +104°F (+40°C): ( Standard altitude mode: Floor
installation/ceiling installation)
+41°F (+5°C) to +95°F (+35°C): (Other than above.)
Rated voltage AC 100 - 240 V, 50/60 Hz
Power consumption 8.7 A, 870 W
During standby:
AC 100 - 120 V: 2 W (when STANDBY MODE is STANDARD)
0.2 W (when STANDBY MODE is LOW)
AC 220 - 240 V: 2 W (when STANDBY MODE is STANDARD)
0.3 W (when STANDBY MODE is LOW)
Dimensions (not including protrusion) 490 mm (W) x 201 mm (H) x 421 mm (D) (projector only)
490 mm (W) x 201 mm (H) x 506 mm (D) (including the terminal cover)
Weight 16 kg*
3
(projector only), 16.5 kg*
3
(including the terminal cover)
Others S-video input Luminance signal: Vp-p=1.0 V 75 Ω (negative sync)
Chrominance signals: Vp-p=0.286 V 75 Ω (burst signal)
Video input Vp-p=1.0 V 75 Ω (negative sync)
Component video
input
YC
B
C
R
: Vp-p=1.0 V 75 Ω (Y) (negative sync)
Vp-p=0.7 V 75 Ω (C
B
, C
R
)
Analog input RGB: Vp-p=0.7 V 75 Ω (negative sync)
YC
B
C
R
: Vp-p=1.0 V (Y) (negative sync) Vp-p=0.7 V (C
B
, C
R
)
HD/CS: TTL-level (negative or positive polarity)
VD: TTL-level (negative or positive polarity)
Digital input (DVI) DVI-D interface (TMDS single link) with HDCP
Digital input (HDMI) HDMI interface (TMDS single link)
Digital input (SDI)*
2
SDI interface:
SD-SDI (YC
B
C
R
4:2:2 10 bits)
HD-SDI (YP
B
P
R
4:2:2 10 bits)
3G-SDI (YP
B
P
R
4:2:2 10 bits)
Replacement part (option/not included in the box)
Spare lamp: VLT-XD8000LP
Option lenses: OL-XD2000SZ*
4
, OL-XD2000LZ*
4
, OL-XD2000TZ, OL-XD8000UZ, OL-XD2000FR
Option color-wheel: CW-FC2
*1: For UD8400U and UD8350U only. For UD8400LU and UD8350LU, see page 76.
*2: For UD8400U and UD8400LU only.
*3: For UD8400U and UD8350U only.
The weight of UD8400LU/UD8350LU is obtained by subtracting the weight of the lens part of UD8400U/UD8350U from the above values.
*4: For UD8400U and UD8350U only.
Important:
• Ask a trained specialist for mounting or replacing the option lens or the option color-wheel. For details, contact your dealer.
