Wiper blade rubber replacement
10-14 Maintenance
10
E01002601685
1. Lift the wiper arm off the windscreen.
2.Pull the wiper blade until its stopper (A)
disengages from the hook (B). Pull the
wiper blade further to remove it.
3. Attach the retainers (C) to a new wiper
blade.
Refer to the illustration to ensure that the
retainers are correctly aligned as you
attach them.
4. Insert the wiper blade into the arm, start-
ing with the opposite end of the blade
from the stopper. Make sure the hook (B)
is fitted correctly in the grooves in the
blade.
5. Push the wiper blade until the hook (B)
engages securely with the stopper (A).
Avoid the combined use of different types of
tyres.
Using different types of tyres can affect vehi-
cle performance and safety.
Wiper blade rubber replace-
ment
Windscreen wiper blades
Do not allow the wiper arm to fall onto the
windscreen. This could damage the glass.
If retainers are not supplied with the new
wiper blade, use the retainers from the old
blade.
