Motorola C350 Series Service Manual

24 January 23, 2003 6809456A82
Disassembly C350 Series
SIM Holder Removal and Replacement
1. Remove the rear housing cover and SIM as described in the procedures.
2. Turn the endo housing over so the antenna and SIM holder are facing up.
3. Gently press down on the SIM holder.
The SIM holder should easily snap out of the endo housing.
4. To replace, turn the endo housing over so that the interior of the housing is
facing up.
5. Insert the SIM holder into the endo housing with the circuit board contacts
facing up and the SIM contacts facing down.
6. Gently press the SIM holder until it snaps into position in the endo housing.
7. Replace the SIM and rear housing cover as described in the procedures.
021029o
Figure 7. SIM Holder Removal and Replacement
B
A
SIM HOLDER
SIM HOLDER
ENDO HOUSING
ENDO HOUSING
DISASSEMBLY
TOOL
