6809456A82 January 23, 2003 41
Level 1 and 2 Service Manual Part Number Charts
Exploded View Parts List
To order parts please use the following Link:
https://wissc.motorola.com/wissc_root/main/BrowserOK.html
(Password is Required)
For information on ordering parts please contact EMEA at +44 131 479 1274.
Table 4. Exploded View Parts List
Item
Number
Motorola Part
Number
Description
Item
Number
Motorola Part
Number
Description
1 AANN4204 Battery 23 See Table 5 Escutcheon
2 - SIM card 24 MHN5433 Front housing assembly
3 - Elastomer 25 1586620P02 Band-decorative (part of item
24)
4 0186606P01 Back Endo Assembly 26 MYN4387 Keypad
5 Included in item 4 SIM Card Switch 27 4086548P01 Mylar metal-domes
6 2689851L01 Shield 100 28 AAUG1330 Transceiver PCB assembly
7 - Microphone Gasket 29 2686610P01 Shield 400
8 5088625L01 Microphone 30 5987772L02 Motor/vibrator
9 - Elastomer speaker 31 Level 3 Part RF test connector
10 5089081 L01 Audio speaker 32 2689852L01 Shield 200
11 0186617P01 Display assembly Philips 33 2689853L01 Shield 300
12 included in item 11 Display shield 34 3970350D01 SIM card connector
13 0309315B07 TORX screw 35 0970312B16 Mini USB connector
14 - Dust gasket 36 0985882K01 Charger connector
15 1370316B33 Motorola logo 37 3986595P01 Battery connector
16 1170314T01 Tape 38 Included in item
42
Tape
17 included in item 11 Keyboard spacer 39 Included in item
42
Tape
18 - - 40 0987837L04 Headset connector
19 - - 41 3886623P01 Connector cover- rubber
20 3286659P01 Gasket 42 AAHN5436A Back housing assembly
21 6186621P01 Lens 43 Included in item 4 Alert transducer
22 N/A Gasket 44 Included in item 4 Alert shield
Notes:
E
There is a danger of explosion if the Lithium ion battery pack is replaced incorrectly.
Replace only with the same type of battery or equivalent as recommended by the
battery manufacturer. Dispose of used batteries according to the manufacturer’s
instructions.
