BASIC LEVEL CHECKS AND SELF TESTS: Troubleshooting
68P80400P73-A 5-7
4. If the image is defective, the camera may need to be replaced via a new flip assembly.
5. Repeat steps 1 to 3.
6. If the image is defective, the main display may need to be replaced via a new flip assembly.
7. Repeat steps 1 to 3.
8. If image is defective, replace the main board.
9. Repeat steps 1 to 3.
10. If the test is successful, power down the unit.
5.6 Troubleshooting
Troubleshooting can help identify the problem and determine the next action to take (continue
testing, replace parts, or send unit to the Radio Support Center). Refer to the iDEN Customer Care
Troubleshooting Guide for information on how to perform common troubleshooting procedures.
5.7 Self-Test Procedures
An i860 unit allows you to conduct automatic self tests to ensure that it is working properly. Self-
test procedures include gathering information from the unit’s displays and testing the functionality
of basic components. These procedures usually do not require test equipment other than a reference
SIM card.
The following self-tests can be performed on an i860 unit:
• Passcode
• Programming Menu Settings
• Call Performance
5.7.1 Passcode Test
Use this test to determine the passcode for the unit.
The passcode test time is approximately 5 minutes:
1. Power on the unit.
2. If the display reads Unit Locked Enter Code, enter 0000 or the 4-digit code provided by the
customer. (If the customer has changed the passcode but does not remember the new code, read
the codeplug to determine the passcode.)
3. If the passcode unlocks the unit, from the Main Menu, select Settings > Security > Phone
Lock, and press
A
under Off.
If the unit does not unlock, repeat the test. If the problem persists, send the unit to the field level
of service.
NOTE: If applicable, ensure that the unit’s codeplug file is copied and retained for future use.
