BASIC LEVEL TEST MODES AND PROCEDURES: Test Modes
68P80400P73-A 6-3
6.1.3 Entering Test Mode
Use this procedure to access test mode.
To enter test mode:
1. Power up the unit. Wait until the power-up sequence is complete before continuing.
NOTE: Steps 2 through 7 must be performed quickly (no more than one second between each key
press).
2. Press #.
IMEI/SIM ID Displays the electronic serial number and SIM ID serial number.
The IMEI is the global name assigned to the mobile station at manufacturing time and should
correspond to the serial-number tag of the unit.
The SIM ID is the SIM electronic serial number and should correspond with the number
stamped on the SIM card.
Pressing OK allows the IMEI/SIM ID to be traced.
Registr Log Displays the Dispatch Log, Interconnect Log, Packet Data Log, Mobile IP Log, and Phone
Rst Log. Registration Log information is updated when the user deselects and selects the
Registr Log choice.
Err/Chan Codes Displays the physical channel that the unit is connected to or the radio link procedure that is
currently active. Also, displays error codes of errors encountered during normal operation if
Err/Chan codes is On. At power up, the Err/Chan Codes is Off.
Current Freq Displays current frequency and band. Pressing OK allows the current frequency and band to
be traced.
Dispatch IDs Displays the Dispatch Group ID affiliated with the unit in the current dispatch-location area.
Also, displays the Dispatch Individual ID affiliated with the unit in the current dispatch
location. Pressing OK allows the dispatch IDs to be displayed periodically.
Band Info Displays primary and secondary bands.
Bandmap Displays the currently selected regional bandmap. Pressing OK allows the bandmap to be
displayed periodically.
Hardware Displays the AFC Offset and Channel Number.
Pressing OK allows the hardware parameters to be traced.
Fatal Err/# Displays the Fatal Error log. This log contains a count of any fatal errors logged during the
unit's automatic self test. Optioning clear empties the log.
Flags Displays the error log. This log contains any errors logged by the unit software. Pressing
Menu when it appears displays the Clearall screen in which the user can clear all the logged
errors.
Resets Displays the Reset Error log. This log contains any errors logged when the user resets the
unit during operation. The most recent reset appears at the top of the list. Pressing Menu
when it appears displays the Clearall screen in which the user can clear all the logged errors.
Coin Cell Displays the Charger and Battery Voltage.
CE Status Indicates accessory type connected to unit.
Table 6-1. Display Screens (Continued)
Name Description
