MODEL SPECIFICATIONS
viii 68P80400P73-A
MODEL SPECIFICATIONS
Specifications subject to change without notice.
GENERAL RECEIVER TRANSMITTER
FCC Designation: AZ489FT5833 Receiver Type: Superheterodyne Transmitter Type Single Conversion
Operational Modes:
800 MHz Band only:
Phone
Private
Group
Circuit Data
Packet Data
Frequency Range: 851-870 MHz
935-940 MHz
Frequency Range: 806-825 MHz
896-901 MHz
Temperature Range:
Operating –10°C to +60°C
Storage (w/o battery) –40°C to +85°C
Channel Spacing: 25 kHz Emission Designator: 18K3D7W
Power Supply:
Battery Type Lithium Ion
Frequency Stability:
Referenced to base
station 0.4 ppm
Modulation Types: Quad 16QAM
Quad 64QAM
Quad QPSK
Recommended
Battery: SNN5704C
SNN5705C
Sensitivity (10%) BER:
(M-16 QAM)
–111 dBm
Frequency Stability:
Referenced to base
station 0.4 ppm
Battery Voltage:
Nominal
Range
3.6 Vdc
3.0 to 4.2 Vdc
Spurious Response
Immunity: -51 dBm
Spurious Emissions:
Conducted
Radiated
–13 dBm
–13 dBm
Dimensions (HxWxD):
w/750mAh 87.3 x 46.8
battery door x 24.2 mm
w/500mAh 87.3 x 46.8
battery door x 21.8 mm
Spurious Radiation:
Above 960 MHz
216–960 MHz
88–216 MHz
30–88 MHz
<500 µV/m.
<200 µV/m.
<150 µV/m.
<100 µV/m.
RF Pulse Avg Power:
(dynamically
adjusted) –11 to +28 dBm
Weight:
(without battery)
109.5 g
Audio Output Power
and Speakerphone
Rating:
(Private and Group
Modes only) into
8 ohms at maximum
volume (nominal
battery voltage) 500 mW
Adjacent Channel
Power:
(at ±25 kHz in 18 kHz
BW)
-55 dB
Distortion at Rated
Audio:
Electrical
Acoustical
5% Max.
10% Max.
