PREPARING FOR FIELD LEVEL TESTING: Exploded View and Parts List
7-16 68P80400P73-A
7.14.1 Component Parts List
Table 7-2. Component List
# Description Part Number Reference
1 Housing, Flip Assembly 1585656F01
2 Hinge 5585592F01
3 Cover, Flip Knuckle, Left 1585720F01
4 Housing, Front 1585653F01
5 Screw, Center 0385693E01
6 Cap, Hinge Button, Right 3885896F01
7 Cover, Hinge Button, Right 3885614F01
8 Housing, Back Assembly 1585325F01
9 Antenna, Retract. 8585744F01
10 Screw, Center 0385693E01
11 Plug, Cover, Antenna Screen 3864307H01
12 Battery, High Capacity Assembly
Battery, Slim Assembly
SNN5705B
SNN5717A
13 Label, Escutcheon See Appendix A
14 Cover, Battery, High Capacity Assembly
Cover, Battery, Slim Assembly
1585658F01
1585617F01
15 Screw, Base 0364016H01
16 PCB, Main —
17 Seal, Audio Front Mic 3285630F01
18 Keypad, Assembly 7585660F01
To Next Page
