11
CALIBRATE
Select Aircraft
Aircraft #1
“name”
Aircraft #2
“name”
Aircraft #7
“name”
Aircraft #4
“name”
Aircraft #5
“name”
Aircraft #3
“name”
Aircraft #6
“name”
Aircraft #8
“name”
Press
Option
CALIBRATE
Press Option
Press
Option
Select Aircraft
Moving Elevator stick
up to advances in
the direct of the arrows.
Moving Elevator stick
down to reverses
the direction.
Press Option from any
selection to define
the aircraft.
When the Option button is pressed
the new aircraft parameters are loaded.
The RF deck frequency will not change
even if the new aircraft is on a different
frequency. You must cycle power to enable
the new frequency.
“name” will display
the aircraft name defined
for the selected configuration.
If the optional secondary
SPROM is enabled then
16 aircraft option will be
selectable.
To Next Page
