MSI 2000 User Manual

47
Select Frequency
CALIBRATE
Select Frequency
Select Frequency
53.1 MHz
Press
Option
CALIBRATE
Press Option
Press
Option
Moving Elevator stick
up to advances in
the direct of the arrows.
Moving Elevator stick
down to reverses
the direction.
Press Option from any
selection to define
the aircraft.
When the Option button is pressed
the new frequency is loaded.
The RF deck frequency will not change
until you turn the radio off and then
back on. You must cycle power to enable
the new frequency.
Select Frequency
53.2 MHz
Select Frequency
53.3 MHz
Select Frequency
53.4 MHz
Select Frequency
53.5 MHz
Select Frequency
53.6 MHz
Select Frequency
53.7 MHz
Select Frequency
53.8 MHz
If OPT2 jumper is installed
then channel 0 through are
selected, 50MHz. The
example shown here is for
53 MHz, OPT1 jumper
installed.
