MSI 2000 User Manual

8
Tachometer Module
When the optional Tachometer module is plugged into the accessory jack on the side of the MicroStar
the second line of the display will read the detected RPM. The MicroStar detects the presents of the
Tach module automatically!
10.5 RA--- 00:00
2Bld RPM = 2430
Example display
The number of prop blades can be defined
in the MISC parameters, Different aircraft
can have different Tach parameters
Another unique feature of the MicroStar is
direct servo drive. Through the same accessory
jack any channel can be used to drive a
servo. This is helpful during programming
and testing.
