34
Overview of Components
4. Reconnect the power cord, power up the computer and install the drivers and
software included in your graphics card package.
5. Right-click the Windows desktop and select NVIDIA Control Panel from the menu,
click on Configure SLI, Surround, PhysX in the left task pane and select Maximize
3D performance in the SLI configuration menu, and then click Apply.
VRAID1: Virtual RAID on CPU Connector
This connector allows you to connect the VROC (Virtual RAID on CPU) key module. You
need to enable the VROC function with Intel
®
RSTe (Intel
®
Rapid Storage Technology
enterprise) driver.
1
1 GND 2 VCC3
3 GND 4 SATA_RAID_KEY
⚠
Important
The VROC key module is purchased separately.
To Next Page
