44
Overview of Components
OC_RT1: OC Retry Jumper
When you close this jumper, the system will keep retrying OC items until it boot up
successfully.
Normal
(default)
Normal
(default)
Keep retrying OC
Force access to the
BIOS and skip OC failure
messages
OC_FS1: OC Force Enter BIOS Jumper
When you close this jumper, the system will be forced access to the BIOS and skip OC
failure messages .
JSLOW1: Slow Mode Booting Jumper
This jumper is used for LN2 cooling solution, that provides the extreme overclocking
conditions, to boot at a stable processor frequency and to prevent the system from
crashing.
Normal
(default)
Enabled
(Please enable this jumper
during BIOS POST.)
⚠
Important
∙
Users will try extreme low temperature overclocking at their own risks. The
overclocking results will vary according to the CPU version.
∙
Please don’t switch to Enabled when power-off or the system will be un-bootable.
OC_RT1
OC_RT1
OC_FS1
OC_FS1
