CHAPTER 4
AMI
®
BIOS USERS GUIDE
4-9
4.4 Advanced Chipset Setup
1. Press <ENTER> on “Advanced Chipset Setup” of the main menu
screen.
AMIBIOS SETUP - ADVANCED CHIPSET SETUP
(C) 1999 American Megatrends, Inc. All Rights Reserved
USB Function Enabled
USB Keyboard Legacy Support Disabled
CPU Latency Timer Disabled
DRAM Page Closing Policy Closed
CD Hole (DC000h - DFFFh) Disabled
Memory Hole Disabled
DRAM Tras/Trc Cycle Time(SCLKs) 6/8
Address Setup Time(SCLKs) 1
CAS# Latency(SCLKs) 3
SDRAM RAS# to CAS# Delay(SCLKs) 3
SDRAM RAS# Precharge 3
Graphics Mode Select UMA 1MB
Onboard Video Chip Enabled
CPU BIST Enable Disabled
ICH Delayed Transaction Disabled
ICH DCB Enable Disabled
****Display Cache Function****
Initialize Display Cache Memory Enabled
Paging Mode Control Closed
RAS-to-CAS Default
Available Options:
Disabled
Enabled
ESC:Exit :Sel
PgUp/PgDn:Modify
F2/F3:Color
2
.
Use <Up> and <Down> to choose the item and <PgUp> and
<PgDn> keys to modify the highlighted item.
3. After you have finished with the Advanced Chipset Setup, press
<ESC> to go back to the main menu.
CAS Latency Slow
RAS Timing Slow
RAS Precharge Timing Slow
To Next Page
