MSI MS-6178 User Manual

CHAPTER 4
AMI
®
BIOS USERS GUIDE
4-24
Parallel Port Mode
This option allows user to choose the operating mode of the onbaord
parallel port. The settings are Normal, SPP/EPP or ECP mode.
EPP Version
This option is for setting which EPP version will be used. The
settings are 1.7 and 1.9.
Parallel Port IRQ
If the onboard parallel mode is not on auto mode, the user can select
the interrupt line for onboard parallel port. We suggest that the user select
the interrupt for the onboard parallel port as shown below:
Parallel Port DMA Channel
This option allows user to choose DMA channel 1 to 3 for the
onboard parallel port on ECP mode.
Onboard parallel port set at
Parallel Port IRQ
LPT1(378H)
LPT2(278H)
LPT3(3BCH)
7
5
5
