CHAPTER 2
HARDW
ARE INST
ALLA
TION
2-10
2.4 Case Connector: JFP1
The Keylock, Power Switch, Reset Switch, Power LED, Speaker
, and HDD
LED are all connected to the JFP1 connector block.
JFP1
Power
Switch
Power LED
+
Reset
Switch
HDD
LED
+
Speaker
Buzzer
(short
pin)
14
15
Keylock
Dual
Color
LED
Single
Color
LED
68
70
