CHAPTER 2
HARDW
ARE INST
ALLA
TION
2-19
2.14 Audio Port Connectors
Line Out
is a connector for Speakers or Headphones.
Line In
is used for
external CD player
, T
ape layer
, or other audio devices.
Mic
is a connector for
the microphones.
Line Out
Line In
Mic
1/8” Stereo Audio Connectors
2.13 Joystick/Midi Connectors
Y
ou can connect joystick or game pad to this connector
.
Joystick/MIDI
77
79
