4 Confi
ure displays to use radar
Setup and configuration of the Broadband radar has been simplified compared to traditional
pulse radars. There is no zero range (time delay), no warm up time, and no burn in required..
The only adjustments needed are:
• Set the scanner height: This is to help the radar calculate for sea clutter.
• Adjust the heading marker. This is to align with the heading marker on the screen with
the center line of the vessel, this will compensate for any slight misalignment of the
scanner during installation. Any inaccuracy will be evident when using MARPA or chart
overlay.
Lowrance HDS radar setup
Enter radar installation by pressing Menu > Settings > Radar > Installation.
To set the antenna height:
• Use the Up / Down arrows to select antenna height from the menu. Use the Left / Right
arrows to adjust the antenna height value. The value will represent the antenna height
above sea level in the units that have selected such as feet or meters.
To start the radar:
• Press pages > Radar > Radar State. Use cursor to edit the radar state. Select transmit to
activate the radar.
To adjust the bearing alignment:
• Use the Up / Down arrows to select bearing alignment.
• Use the Left / Right arrows to adjst bring the heading line on the screen to represent the
actual heading of the boat.
• Point the boat to the end of a head land or peninsular. Adjust the bearing alignment so
the heading line touches the end of the same head land or peninsular.
For more operational information please refer to the HDS operation guide.
Configure displays to use radar | 21
