Simrad NX40/45 or Northstar M84/M121 radar setup
Your display may need a software upgrade to get full functionality of the Broadband radar.
Please contact your dealer for further information.
To enable the radar functionality:
• Press Setup (NX) or menu twice to display the Setup menu, then select System.
• Set Radar to
.
When the radar is enabled, it will turn on, and enter standby mode.
Antenna height
• Press Menu twice > Radar > Installation
Select Antenna height then enter the height of the antenna above sea level.
Zero bearing
Adjust this on a chart window with the radar overlay on.
• Press Menu twice > Radar > Installation
• Select Zero bearing then use the arrow keys to enter the new bearing angle.
Accurate heading data is required
Your display may need a software upgrade to get full functionality of the Broadband radar.
Please contact your dealer for further information.
Configure displays to use radar | 23
