3-3
SYMBOL CODE DESCRIPTION
5 --- MAC. SCREW-MB M3.0*4.0L,Zn-Cc
SYMBOL CODE DESCRIPTION
6 --- MAC. SCREW-MRFW M3.0*4.0L,NI
7 --- NUT #4-40*5.0L (BRONZE + Ni)
8 79PZ0014 LCD MAIN BD ASS'Y
9 79PZ0008 INVERTER DC-AC T65I008.00
W05
W04
5
9
8
W07
7
6
CN5 CN4
CN1
CN2 CN3
