Configuration Note 4. Configuring AudioCodes E-SBC
Version 7.0 23 AudioCodes Mediant E-SBC
4 Configuring AudioCodes E-SBC
This chapter provides step-by-step procedures on how to configure AudioCodes E-SBC for
interworking between IP-PBX and the BroadCloud SIP Trunk. These configuration
procedures are based on the interoperability test topology described in Section 2.4 on page
10, and includes the following main areas:
E-SBC WAN interface - BroadCloud SIP Trunking environment
E-SBC LAN interface - IP-PBX environment
This configuration is done using the E-SBC's embedded Web server (hereafter, referred to
as Web interface).
Notes:
• For implementing IP-PBX and BroadCloud SIP Trunk based on the configuration
described in this section, AudioCodes E-SBC must be installed with a Software
License Key that includes the following software features:
√ SBC
√ Security
√ DSP
√ RTP
√ SIP
For more information about the Software License Key, contact your AudioCodes
sales representative.
• The scope of this interoperability test and document does not cover all security
aspects for connecting the SIP Trunk to the IP-PBX environment. Comprehensive
security measures should be implemented per your organization's security policies.
For security recommendations on AudioCodes’ products, refer to the Recommended
Security Guidelines document.
• Before you begin configuring the E-SBC, ensure that the E-SBC's Web interface
Navigation tree is in Advanced-menu display mode. To do this, select the Advanced
option, as shown below:
Note that when the E-SBC is reset, the Navigation tree reverts to Basic-
menu display.
