AudioCodes Mediant E-SBC 36 Document #: LTRT-12490
SV9100 IP-PBX & BroadCloud SIP Trunk
4.6 Step 6: Configure IP Profiles
This step describes how to configure IP Profiles. The IP Profile defines a set of call
capabilities relating to signaling (e.g., SIP message terminations such as REFER) and
media (e.g., coder and transcoding method).
In this interoperability test topology, IP Profiles need to be configured for the following IP
entities:
IP-PBX - to operate in non-secure mode using RTP and UDP
BroadCloud SIP trunk - to operate in non-secure mode using RTP and UDP
To configure IP Profile for the IP-PBX:
1. Open the IP Profile Settings page (Configuration tab > VoIP > Coders and Profiles
> IP Profile Settings).
2. Click Add.
3. Click the Common tab, and then configure the parameters as follows:
Parameter Value
Index
1
Name
IP-PBX (see Note on page 31)
Figure 4-14: Configuring IP Profile for IP-PBX – Common Tab
