AudioCodes Mediant E-SBC 32 Document #: LTRT-12490
SV9100 IP-PBX & BroadCloud SIP Trunk
4.5 Step 5: Configure Proxy Sets
This step describes how to configure Proxy Sets. The Proxy Set defines the destination
address (IP address or FQDN) of the IP entity server. Proxy Sets can also be used to
configure load balancing between multiple servers.
For the interoperability test topology, two Proxy Sets need to be configured for the following
IP entities:
IP-PBX
BroadCloud SIP Trunk
The Proxy Sets will be later applying to the VoIP network by assigning them to IP Groups.
To configure Proxy Sets:
1. Open the Proxy Sets Table page (Configuration tab > VoIP menu > VoIP Network >
Proxy Sets Table).
2. Add a Proxy Set for the IP-PBX. You can use the default Proxy Set (Index 0), but
modify it as shown below:
Parameter Value
Proxy Set ID
0
Proxy Name
IP-PBX (see Note on page 31)
SBC IPv4 SIP Interface
IP-PBX
Proxy Keep Alive
Using Options
Figure 4-9: Configuring Proxy Set for IP-PBX
