NEC SV9100 Configuration Note

AudioCodes Mediant E-SBC 30 Document #: LTRT-12490
SV9100 IP-PBX & BroadCloud SIP Trunk
4.4 Step 4: Configure SIP Signaling Interfaces
This step describes how to configure SIP Interfaces. For the interoperability test topology,
an internal and external SIP Interface must be configured for the E-SBC.
 To configure SIP Interfaces:
1. Open the SIP Interface Table page (Configuration tab > VoIP menu > VoIP Network
> SIP Interface Table).
2. Add a SIP Interface for the LAN interface. You can use the default SIP Interface
(Index 0), but modify it as shown below:
Parameter Value
Index
0
Interface Name
IP-PBX (see Note on page 31)
Network Interface
Voice
Application Type
SBC
UDP Port
5060
TCP and TLS
0
Media Realm
MRLan
3. Configure a SIP Interface for the WAN:
Parameter Value
Index
1
Interface Name
BroadCloud (see Note on page 31)
Network Interface
WANSP
Application Type
SBC
UDP Port
5060
TCP and TLS
0
Media Realm
MRWan
