Version 7.0 63 AudioCodes Mediant E-SBC
Configuration Note A.AudioCodes INI File
A AudioCodes INI File
The ini configuration file of the E-SBC, corresponding to the Web-based configuration as
described in Section 4 on page 23, is shown below:
Note: To load and save an ini file, use the Configuration File page (Maintenance tab >
Software Update menu > Configuration File).
;**************
;** Ini File **
;**************
;Board: Mediant 500 E-SBC
;HW Board Type: 69 FK Board Type: 76
;Serial Number: 4965606
;Slot Number: 1
;Software Version: 7.00A.035.012
;DSP Software Version: 5014AE3_R => 700.40
;Board IP Address: 192.168.100.15
;Board Subnet Mask: 255.255.255.0
;Board Default Gateway: 192.168.100.254
;Ram size: 369M Flash size: 64M Core speed: 500Mhz
;Num of DSP Cores: 1 Num DSP Channels: 50
;Num of physical LAN ports: 4
;Profile: NONE
;;;Key features:;Board Type: 76 ;IP Media: Conf VXML
VoicePromptAnnounc(H248.9) POC ;Channel Type: RTP DspCh=50 ;Coders: G723
G729 G728 NETCODER GSM-FR GSM-EFR AMR EVRC-QCELP G727 ILBC EVRC-B AMR-WB
G722 EG711 MS_RTA_NB MS_RTA_WB SILK_NB SILK_WB SPEEX_NB SPEEX_WB ;QOE
features: VoiceQualityMonitoring MediaEnhancement ;DSP Voice features:
IpmDetector RTCP-XR AMRPolicyManagement ;FXSPorts=3 ;FXOPorts=1
;BRITrunks=12 ;DATA features: ;Security: IPSEC MediaEncryption
StrongEncryption EncryptControlProtocol ;Control Protocols: MGCP MEGACO
H323 SIP TPNCP SASurvivability SBC=50 MSFT CLI TRANSCODING=50 FEU=600
TestCall=5 EMS ;Default features:;Coders: G711 G726;
;------ HW components------
;
; Slot # : Module type : # of ports
;----------------------------------------------
; 2 : FXS : 3
; 3 : FXO : 1
;----------------------------------------------
[SYSTEM Params]
SyslogServerIP = 192.168.100.25
EnableSyslog = 1
NTPServerUTCOffset = 7200
;VpFileLastUpdateTime is hidden but has non-default value
NTPServerIP = '0.0.0.0'
;LastConfigChangeTime is hidden but has non-default value
